FANUC A06B-6066-H234

FANUC has developed this AC servo drive A06B-6066-H234, tailored to meet the needs of multiple industries. Its innovative design promises reliable performance and unparalleled accuracy for various applications.

This model A06B-6066-H234 offers dependable performance across the most rigorous tasks. With a maximum input current of 13.2 A at rated load, this product is ideal for any needs.

Technical Description of A06B-6066-H234:

The A06B-6066-H234 model's output performance is top-notch, reaching 179 V and 14.7 A at 100 Hz €“ however, ensure the power source you are utilizing can handle it without voltage drops when under maximum load by having an extra allowance in its capacity.

This AC servo drive A06B-6066-H234 is a robust and economical motor system providing optimal speed and torque control. The ideal voltage frequency for this module ranges from 50 to 60 Hz with an accuracy of +/- 1 tolerance.

The A06B-6066-H234 model requires a 3-phase power supply with nominal voltages of 200, 220, or 230 V AC. Optimize the fan motor for specific wind speeds.

This drive's optimized user experience ensures efficient setup and operation, while its sophisticated performance-enhancing capabilities deliver precise motion control with consistently excellent repeatability.

The A06B-6066-H234 servo amplifier is equipped with LED indicators on printed circuit boards, allowing monitoring of its state and providing the ability to detect any potential issues quickly.

Ambient Conditions (Operating, Storage, and Installation):

The optimal temperature for maximum efficiency from the A06B-6066-H234 model lies between 0 - 40°C. It is essential to reduce the output power when operating at higher temperatures to maintain a steady level of operation.

To ensure optimum performance, store the AC servo drive indoors in a dry area away from direct sunlight. The ideal temperature range for storing this model is between -20 °C and +60°C.

Installing the A06B-6066-H234 model at elevations up to 1,000 meters above sea level allows for reliable operation without any additional precautions; however, when handling, take appropriate diligence if you conduct operations beyond this altitude with a temperature decrease of one degree Celsius per 100-meter increase in elevation relative to 1000 m (ASL).

Start-Up Instructions for the Servo Drive:

Do not turn off the power while applying all settings to the device. The model must be installed and operated by a certified specialist.

To ensure safety, keep the system in its emergency stop state when adjusting parameters. You can alter menu displays in excitatory mode, but the internal data will remain unchanged. Alterations to settings will only take effect once committed.

Before instituting a closed-loop system, users should verify the performance of their machine in a semi-closed framework by utilizing an integrated pulse coder on the motor.

General Instructions:

The incorrect pairing of a servo amplifier and motor can cause trouble - from subtle issues like vibration to potentially disastrous failure. Optimal performance and safety require making the right connections.

The A06B AC servo motor and amplifier may require one-wire grounding to guarantee safely negligible leakage current. However, the exact value of this commercial frequency component depends on the type of measuring instrument utilized during the assessment.
