FANUC A06B-6102-H215#H520

The Fanuc A06B-6102-H215#H520 is a high-performance spindle module designed to be reliable and precise, and it comes with CE approval to ensure the highest standards of excellence. With outstanding speed and torque, this module is ideal for applications that require top-notch machining capabilities.

Technical Specifications of Fanuc A06B-6102-H215#H520:

The Fanuc A06B-6102-H215#H520 spindle module is a versatile machine module. It's easy to integrate into manufacturing processes and gives the flexibility to design the machine.

The module is built to handle heavy-duty cutting tasks with a maximum torque of 52 Nm, ensuring high-precision machining applications. Running on a 200-240 VAC power source, it's compatible with various manufacturing equipment, drawing only 3.3 kW to reduce operating costs. It's an efficient, powerful, and reliable machine module perfect for heavy-duty tasks.

The A06B-6102-H215#H520 spindle module packs a punch with its high torque output, perfect for tackling tough cutting tasks and precise machining. Maximum torque of 52 Nm and efficient power consumption of around 3.3 kW helps lower operational costs and ensures reliable performance. This spindle module is fit for various manufacturing processes that require quick and precise movements.

The spindle module is a high-tech wonder that provides precise position feedback and efficient control of spindle speed and position. Equipped with a 20-bit absolute encoder and a PPR rating 4,096, this machine delivers unparalleled performance and reliability in modern manufacturing processes.

The amplifier module is lightweight and portable, coming in at about 8.5kg with measurements of 340mm (W) x 90mm (H) x 400mm (D). You can use the A06B-6102-H215#H520 amplifier module with the servo motors from the iF and I series.

Installation and Operating Guideline:

The A06B spindle module is a versatile tool with a temperature range of 0°C to 40°C. This sturdy spindle module can handle temperatures as low as -10°C and as high as 50°C without any impact on performance. The design to operate in high-humidity environments makes it an excellent choice for facilities where moisture levels are a major concern.

To get peak performance of Fanuc A06B-6102-H215#H520, Regular maintenance is key to ensuring that your spindle is firing on all cylinders. It includes thoroughly cleaning, keeping everything lubricated, and inspecting each component to ensure everything functions smoothly.

Wiring Instructions:

The spindle module A06B-6102-H215#H520 motor connection terminals will be connected to the motor's wiring. Check out the trusty motor manufacturer's wiring diagram for guidance. With a little attention to detail, the spindle module and motor spun in perfect harmony in no time.

Getting the module up and running requires precision and attention to detail. One crucial component is the encoder for measuring rotation speed. To connect the two, find the specific terminals on the spindle module and match them up with the corresponding wires on the encoder for the smooth working of the module.

Safety Instructions:

Ensuring that the control system for Fanuc A06B-6102-H215#H520 is correctly calibrated. Delivering the correct signals to the spindle module ensures it's running at the right speed and torque.

Proper temperature, humidity, and hygiene can keep the spindle module performing at its best. Make sure to keep things clean and maintain a comfortable environment for optimal results.
