TECHNICAL SPECIFICATIONS

FANUC A06B-6111-H045#H550

Industries requiring high-precision machining capabilities choose the A06B-6111-H045#H550 spindle amplifier module product line. It offers excellent performance and smooth operation, with a maximum rotational speed of 15,000 RPM, making it ideal for fast-paced tasks that demand accuracy and integrity.

Technical Specifications of FANUC A06B-6111-H045#H550:

The FANUC A06B-6111-H045#H550 module provides an unmatched level of precision and control with its 25 Nm maximum torque, making it ideal for high-speed machining. Low moment inertia ensures that spindle movements are rapid yet precise - perfect for those tasks requiring quick responsiveness from their machinery.

This spindle amplifier module is a lightweight solution for industrial applications, weighing only 25 kg. It makes it easy to install and move around. With a 200 - 240VAC power supply voltage requirement and 4.4 kW of energy consumption allow, integrating the module into most existing manufacturing processes will be hassle-free.

The FANUC A06B-6111-H045#H550 module is designed to handle even the toughest machining applications. With a maximum torque power of 10.2 kW, it offers exceptional cutting force and can reach speeds up to 15,000 RPM--perfect for high-speed tasks that require accuracy and precision with difficult materials.

The FANUC spindle amplifier module is designed to maximize the accuracy and precision of spindle operation with a 1,000,000 pulse per revolution high-resolution encoder. An optimal load inertia moment to shaft inertia ratio of 5:1 helps make sure operations involving rapid acceleration or deceleration are smooth and efficient.

The FANUC A06B-6111-H045#H550 boasts an IP67-certified housing and insulation value of 2.0 MΩ or greater, providing superior protection from dust and water while ensuring reliable operation for its spindle.

The module supports communication protocols, including Ethernet/IP, DeviceNet, and CC-Link. The amplifier module is compatible with FANUC's servo motor series iSVSP and iSV, and it can communicate with other devices and networks using the serial interface.

Wiring Instructions:

To successfully and safely use FANUC A06B-6111-H045#H550, it is essential to ensure that all three components' power supply, motor, and encoder meet the technical specifications outlined in its documentation. Connect each component to its respective labeled terminals on the module carefully; incorrect installation of any part may cause damage or malfunction.

When using the module to cater for the event of an emergency, having properly connected the "24VDC" and "STO" terminals will quickly bring your spindle to a full stop. Do not overlook connecting the ground wire to its designated terminal to ensure optimal safety.

Safety Instructions:

Ensure safety and the reliability of A06B-6111-H045#H550 with the best practices. To ensure optimal performance, double-check that all wiring is securely connected during installation by a qualified technician following the instruction manuals. Be sure personal protective equipment like glasses or gloves are worn when handling installation.

Servicing FANUC A06B-6111-H045#H550 modules by strictly adhering to the manufacturer's guidelines. Please ensure all necessary shutdown procedures are completed before initiating maintenance--including disconnecting power and allowing moving parts to cease operation. The unauthorized modifications or alterations could be hazardous.

The control system of the A06B-6111-H045#H550 module offers dynamic torque control, spindle load monitoring, and real-time feedback on speed and position, providing reliable operation. With packed and protective functions like overcurrent protection for extra safety, the user-friendly programming interfaces set up the module quickly.
