TECHNICAL SPECIFICATIONS

FANUC A06B-6124-H106

The FANUC A06B-6124-H106 servo amplifier is a high-powered and comprehensive solution for businesses requiring optimum motor performance. This product seamlessly integrates with the renowned series 30i/31i/32i CNC controllers, making it ideal for use in industries ranging from heavy manufacturing to delicate fabrication.

Technical specifications:

The servo amplifier features a range of advanced technical specifications, including output capacity, control type, and frequency response. Either analog voltage references or CC link communication technology efficiently control the communication, using a pulse train reference input .

The power supply system of FANUC A06B-6124-H106 ranges from 200 to 240 volts across three phases and runs at a frequency of 50/60 hertz. It delivers up to 5.5 kilovolt amperes for an output capacity of 11 KW. It gives maximum current performance peaking at 12 amps.

This system offers three control features: velocity, torque, and position. It also ensures safe operation with robust protection against over current, voltages out-of-range, or overheating issues in varying environments, ranging from 0 to 55°C temperature levels and 10-90% relative humidity (non-condensing).

Installing and Configuring Instructions:

To ensure optimal safety and performance, correctly install the FANUC A06B-6124-H106 servo amplifier. This device has impressive dimensions of 200 x 290 x 250 mm yet weighs only 5.5kgs - making it a lightweight but powerful addition to your CNC machine.

Before installing this component, switch off the power and mount the servo amplifier onto a suitable surface. Ensure that you securely attach it and ensure the wiring obstruction.

Ensure a secure connection between the AC power supply and the servo amplifier with an appropriate cable. Then, connect the servo motor to its designated server amplifier by double-checking wiring accuracy and security.

For optimal performance, keep your motor's power cables as short as possible to minimize electromagnetic interference. Additionally, set the servo amplifier parameters to suit your application's requirements.

Different methods, such as digital inputs and outputs, analog inputs and outputs, and serial communications, can set up the FANUC A06B-6124-H106 servo amplifier. Velocity control, torque control, and position control modes are all configurable for the servo amplifier.

With the help of a serial cable, join a computer to the servo amplifier. To set up the servo amplifier settings, use the FANUC PC software. Choose the preferred control mode (velocity, torque, or position control) and select the appropriate parameters.

To protect the servo amplifier from overcurrent, overvoltage, low voltage, and overheating, configure the protective features. To maximize the performance of the servo amplifier and servo motor for your application, fine-tune the servo amplifier settings.

After configuring the servo amplifier, powering up the CNC machine, and rigorously testing both the motor and A06B-6124-H106 to confirm their functioning, secure them in a controlled environment. Please ensure there are no vibrations within its vicinity for optimally reliable performance.

Regular Maintenance of FANUC A06B-6124-H106:

Maintenance of the FANUC A06B-6124-H106 servo amplifier is to ensure that they operate reliably and efficiently.

To guarantee optimal performance of the servo amplifier and motor, monitoring their operating temperature is essential. If hot conditions arise above recommended levels, take the appropriate actions for cooling them off.

Keep your equipment in top condition by conducting regular diagnostic tests on the servo amplifier as outlined in manufacturer guidance. Additionally, make sure that no dust or debris has accumulated on these components with a good blast from compressed air.
