Description

FANUC A06B-2041-B605#0042

The FANUC A06B-2041-B605#0042 is a servo motor designed for high-performance applications in the industry. The motor is commonly used in CNC machines and robotics due to its high torque and reliability. It comes with advanced control features

Advanced Technology and Design:

The FANUC A06B-2041-B605#0042 servo motor uses advanced technology and features to meet industrial requirements. The motor has a maximum of 2000rpm and a continuous torque of 27Nm, ensuring its fast response for completing industrial tasks.

Motor housing is durable enough to perform consistently in harsh industry environments. It can operate at temperatures ranging from 0°C to 40 °C. Its design is also compact, although it weighs 24kg. Using advanced materials and design methodologies in its construction helps reduce wear and tear.

The motor works at the frequency of 133Hz output and voltage input of 149AC Voltage while maintaining an output of 4.3kW constantly at 17A of AC current. The power factor of the motor is 97%.

The motor can be controlled with different analogue and digital input signals.10V is used for controlling the speed and torque of the motor in the form of analogue input. The motor also supports Pulse train input for precise Positioning control. The motor comes with an IP65 rating and insulation of class F to meet the harsh environment of the industry.

Performance and Efficiency:

The FANUC A06B-2041-B605#0042 servo motor gives exceptional efficiency that no other motor has. This motor is designed to work at low rpm while maintaining the high torque required in precise control applications.

The motor is rated at a power output of 4.3kW and an efficiency of over 90%. It consumes very little energy and reduces operational costs. The motor's design minimises heat generation, maintaining optimal performance and reducing the need for extensive cooling systems, with a thermal resistance of 0.2 K/W.

The motor efficiency is enhanced by the robust construction and high-quality components, which reduce heat generation and energy loss.

Versatile Applications:

The versatility of the FANUC A06B-2041-B605#0042 makes it suitable for a wide range of industrial applications. In CNC machining, this motor plays a crucial role in ensuring accurate and precise movements. The position accuracy of ±0.01° also makes it a preferred choice in robotics.

The motor is used in robotics to automate the processes and do precise movements. The motor's fast feedback mechanism such as the Pulsecoder ?iA 1000, ensures accurate control, essential for tasks such as assembly, welding, and material handling.

The FANUC A06B-2041-B605#0042 is used in other industries for driving conveyor belts, Printing and packaging machines, weaving and knitting machines in the textile industry, and automated surgical types of equipment and tools where precision and accuracy are highly demanded.

Frequently Asked Questions:

What is the maximum speed of the FANUC A06B-2041-B605#0042 servo motor?

The FANUC A06B-2041-B605#0042 servo motor operates at a maximum speed of 2000 RPM, allowing for efficient and rapid movement in various industrial applications.

What is the peak torque output of the FANUC A06B-2041-B605#0042?

The FANUC A06B-2041-B605#0042 provides a peak torque of 27 Nm, ensuring robust performance under high load conditions.

What Protection does the FANUC A06B-2041-B605#0042 uses?

The FANUC A06B-2041-B605#0042 features an IP65 rating and insulation of class F to meet the harsh environment of the industry. Its body is highly durable for industrial applications.

Product Specifications Table

Attribute	Specifications
Power Rating	4.3kW
Peak Torque	27Nm
Maximum Speed	2000rpm
Output Frequency	133Hz
Insulation Class	Class F
Voltage Range	149V/td>
Weight	24kg
Operating Temperature	0°C to 40°C
Current rating	17A
Protection Rating	IP65
