TECHNICAL SPECIFICATIONS

FANUC A06B-6066-H233

You can utilize this highly sophisticated FANUC AC servo drive A06B-6066-H233 in various settings. The advanced engineering and design make it an ideal choice for any application requiring top-notch performance.

This drive A06B-6066-H233 offers a straightforward user experience for hassle-free installation and usage, plus it packs powerful features to maximize productivity. Enjoy precise motion control and consistent repeatability with this exceptional device.

Technical Description of A06B-6066-H233:

This AC servo drive A06B-6066-H233 offers superior rotational speed and torque control with an efficient power system. It operates at a frequency between 50-60 Hz, allowing for accuracy to within 1 Hz - perfect for precise motor control in any application.

The A06B-6066-H233 model is engineered to deliver superior performance, even under intense pressure. It requires 13.2 A of current at the rated load for optimal operation. The model operates with a nominal voltage rating of 200-230V AC and needs to be kept cool via an integrated fan motor which provides optimal wind speed.

To ensure the optimum performance of this model A06B-6066-H233, it is recommended to use a power source with an output capacity capable of accommodating its peak load rating of 179 V and 14.7 A at 100 Hz, avoiding any potential issues due to voltage drop.

The LED indicators on servo amplifiers provide a fast, reliable way to detect potential trouble. These visual cues are essential for illuminating possible problems promptly - ensuring the smooth operation of your system.

Ambient Conditions (Operating, Storage, and Installation):

In order to ensure optimal performance, the A06B-6066-H233 model should be kept indoors at a temperature between -20 °C and +60°C. Additionally, store the model in a dust-free and moisture-free area and avoid direct exposure to sunlight.

Ensure the model's environment stays cool by keeping its ambient temperature between 0 - 40°C. When operating at higher temperatures, be mindful of reducing output power for the motor not to exceed recommended conditions.

With anticipated operation in extreme high-altitude conditions, the model A06B-6066-H233 can be installed and operated conveniently up to a maximum height of 1,000 meters above sea level. Special precautions are not necessary even when operating at higher heights; for each additional 100 m beyond 1,000 m altitude elevation, the ambient temperature will drop approximately by one degree Celsius.

Start-Up Instructions for the Servo Drive:

While optimizing parameters, it is essential to keep the power running until you achieve optimization, even if an alarm suggests shutting it down.

When the system is in an emergency, parameters must remain fixed. However, once it reaches its excitation phase, it can alter menu values; the system refuses to update parameter updates and leaves any internal data unchanged and unmodified.

Before engaging a fully-functioning closed loop system, it's important first to assess how the machine would perform in a semi-closed loop configuration - utilizing pulse coder data.

General Instructions:

Using the wrong combination of an amplifier and motor in a connection can cause failure. It could lead to malfunction, such as excess vibration from the motor. Correctly matching the accompanying motors with their appropriate servo amplifiers is essential.

When using one-wire grounding, the AC servo motor and amplifier produce approximately one mA of commercial frequency leakage current. However, different values may result from utilizing the instrument.
