TECHNICAL SPECIFICATIONS

FANUC A06B-6090-H244

The FANUC A06B-6090-H244 servo amplifier module is an impressive AC drive unit featuring a 2-axis configuration and sophisticated control algorithms for optimizing motion performance. This cutting-edge technology promises accurate, energy-efficient motions in various industrial settings.

With advanced safety features, a compact design, and multiple communication options, A06B-6090-H244 is an ideal choice for reliable motion control systems.

Whether you need to replace faulty equipment or upgrade your current setup, this module provides stable operation and easy integration into existing structures.

Technical Details of FANUC Servo Amplifier:

A06B-6090-H244 servo amplifier module is an ideal motion control solution for demanding applications. It offers a robust and dual-axis output current of 8.7A at 200V and 230 VAC input voltage - capable of delivering the highest levels of precision performance in multiple industrial settings.

This servo amplifier module provides a reliable and safe operation for 50 to 60 Hz AC-powered systems, featuring advanced protection features such as overcurrent and overvoltage protection.

It also has multiple communication options, like fiber optic, serial or parallel connections, that allow easy integration into existing setups.

The A06B-6090-H244 servo amplifier module offers a powerful combination of current and voltage control and an output frequency of 2000 Hz.

With its position feedback function and range of I/O arrangements that read limit switches, analog process variables, and complex positioning positions for greater accuracy in motion control applications - this reliable solution enables maximum performance with precise results across various industrial settings.

Ambient Conditions:

The A06B-6090-H244 servo amplifier module is designed to handle even the most extreme ambient conditions. Rated for a wide temperature range of 0°C to 55°C (32°F to 131 °F) and Humidity levels from 10% - 95%, it's an ideal choice for mission-critical applications in harsh working environments.

The A06B-6090-H244 servo amplifier module can withstand even the most grueling conditions.

Encased in protective armor and capable of withstanding dust, vibration, and other external factors that could harm less sturdy equipment, this unit promises long-lasting durability for your most challenging applications.

Essential Components of A06B-6090-H244:

This servo amplifier module requires two key components: the wiring board A20B-2002-0157 and PCB A20B-2002-0032/03B.

With its compact design constructed out of high-quality materials, the former is responsible for connecting all other parts within this complex network, such as servo amplifiers, operator panels, and power supply units, catering to nearly any model of FANUC from 0 series up through 15 & 16/18 varieties to guarantee performance with optimal longevity.

The PCB A20B-2002-0032/03B is an integral component of CNC control systems, connecting and powering the various electronic components. Compatible with multiple models, this robust printed circuit board showcases high-quality materials to ensure durability and reliability for seamless operations over time.

Precautionary Measures:

Proper installation and wiring of the module are paramount for safe operation. Always call a qualified technician to perform the necessary procedures: following manufacturer instructions, adhering to local electrical codes and regulations, and adequately grounding all wires - these steps are essential for safeguarding against shocks or other potential safety hazards.

To keep the module running safely and effectively, regular maintenance is necessary. To prevent overheating or other hazards, regularly inspect and clean to avoid the accumulation of dust or debris.

Should any signs of damage, wear, or corrosion appear during this process, they must be tended to immediately for optimal safety conditions to be maintained in the future.
