FANUC A06B-6096-H305
FANUC A06B-6096-H305
The FANUC A06B-6096-H305 is a dependable and sturdy servo amplifier in the prestigious FANUC A06B family. This amplifier is built for great performance and precision, making it essential in numerous industrial applications. Thanks to its innovative features and strict safety regulations, servo systems are guaranteed to be efficient and long-lasting with the A06B-6096-H305.
Technical Specifications:
The FANUC A06B-6096-H305 servo amplifier is a robust and efficient component for precise control of servo motors in industrial applications. This amplifier is ideal for medium-to-high-power applications because of its 3.1 kW rated input power and input voltage range of 283-325 V. It is a flexible option for a variety of settings because it can keep the motor running smoothly even in the most extreme conditions.
The A06B-6096-H305 has rated current specifications for several axes, a crucial characteristic. The rated current of 3.0 A is ideal for handling lighter weights and maintaining constant performance throughout both the Land M-axes.
On the other hand, the N-axis can easily handle bigger loads thanks to its considerably higher current of 12.5 A. The amplifier can handle different applications effectively because of the diversity in current ratings.
The amplifier has an output voltage cap of 230 V to ensure it works with all kinds of servo motors. This high output voltage drives the motors, allowing exact control over speed and position. A heatsink and a small form factor make the amplifier ideal for use in a wide range of industrial systems, and efficient thermal management is another feature of its design.
Safety Standards:
The FANUC A06B-6096-H305 is safe for use since it meets the requirements of the widely used VDE0160 standard. Users can have faith in the servo amplifier's operating reliability because it meets all the required safety and performance standards. Adhering to strict safety regulations makes the industrial setup where the amplifier is installed safer, decreasing hazards related to electrical failures.
Protection Features:
The A06B-6096-H305 has multiple safeguards to keep it running smoothly and reliably for a long time. Its exterior heatsink is important for avoiding overheating and dissipating operation-generated heat.
The amplifier is equipped with multiple alerts that notify users of possible problems. When the internal fan stops, the control power voltage drops, the DC link voltage drops, and the regenerative discharge control circuit fails, these alarms will go off. These alarms are crucial to avoid unanticipated downtime and conduct preventive maintenance.
The A06B-6096-H305 also has a dynamic brake circuit failure alarm and protection against over-current on the L and M axes. By limiting the amplifier's operation to safe parameters, these safeguards lessen the likelihood of harm coming to the amplifier and any linked servo motors. These extensive safety features demonstrate that the amplifier was designed with dependability and safety in mind, especially for use in harsh industrial settings.
Frequently Asked Questions:
How does the FANUC A06B-6096-H305 ensure motor safety during operation?
The A06B-6096-H305 has multiple alarms, including one for a dynamic brake circuit failure and one for over-current protection on the L and M axes. These safeguards ensure that any linked servo motors will run smoothly and without incident.
What are the power input and current for the N-axis of the FANUC A06B-6096-H305 servo amplifier?
The FANUC A06B-6096-H305 servo amplifier has a rated power input of 3.1 kW and a rated current of 12.5A for the N-axis.
Does the FANUC A06B-6096-H305 comply with any safety standards?
Yes, it meets the safety requirements of DIN VDE 0160. This compliance guarantees its dependable functioning and meeting of critical safety and performance standards.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Type | Servo Amplifiers |
| Rated Voltage Input | 283-325 V |
| Rated KW Input | 3.1 kW |
| Max Output Voltage | 230 V |
| Rated L axis current | 3.0 A |
| Rated M axis current | 3.0 A |
| Rated N axis current | 12.5 A |
| Safety Standard | DIN VDE 0160 |
| Protection Features | Various alarms, external heatsink |
| Compliance | DIN VDE 0160 |
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
FANUC A06B-6096-H305
The FANUC A06B-6096-H305 is a dependable and sturdy servo amplifier in the prestigious FANUC A06B family. This amplifier is built for great performance and precision, making it essential in numerous industrial applications. Thanks to its innovative features and strict safety regulations, servo systems are guaranteed to be efficient and long-lasting with the A06B-6096-H305.
Technical Specifications:
The FANUC A06B-6096-H305 servo amplifier is a robust and efficient component for precise control of servo motors in industrial applications. This amplifier is ideal for medium-to-high-power applications because of its 3.1 kW rated input power and input voltage range of 283-325 V. It is a flexible option for a variety of settings because it can keep the motor running smoothly even in the most extreme conditions.
The A06B-6096-H305 has rated current specifications for several axes, a crucial characteristic. The rated current of 3.0 A is ideal for handling lighter weights and maintaining constant performance throughout both the Land M-axes.
On the other hand, the N-axis can easily handle bigger loads thanks to its considerably higher current of 12.5 A. The amplifier can handle different applications effectively because of the diversity in current ratings.
The amplifier has an output voltage cap of 230 V to ensure it works with all kinds of servo motors. This high output voltage drives the motors, allowing exact control over speed and position. A heatsink and a small form factor make the amplifier ideal for use in a wide range of industrial systems, and efficient thermal management is another feature of its design.
Safety Standards:
The FANUC A06B-6096-H305 is safe for use since it meets the requirements of the widely used VDE0160 standard. Users can have faith in the servo amplifier's operating reliability because it meets all the required safety and performance standards. Adhering to strict safety regulations makes the industrial setup where the amplifier is installed safer, decreasing hazards related to electrical failures.
Protection Features:
The A06B-6096-H305 has multiple safeguards to keep it running smoothly and reliably for a long time. Its exterior heatsink is important for avoiding overheating and dissipating operation-generated heat.
The amplifier is equipped with multiple alerts that notify users of possible problems. When the internal fan stops, the control power voltage drops, the DC link voltage drops, and the regenerative discharge control circuit fails, these alarms will go off. These alarms are crucial to avoid unanticipated downtime and conduct preventive maintenance.
The A06B-6096-H305 also has a dynamic brake circuit failure alarm and protection against over-current on the L and M axes. By limiting the amplifier's operation to safe parameters, these safeguards lessen the likelihood of harm coming to the amplifier and any linked servo motors. These extensive safety features demonstrate that the amplifier was designed with dependability and safety in mind, especially for use in harsh industrial settings.
Frequently Asked Questions:
How does the FANUC A06B-6096-H305 ensure motor safety during operation?
The A06B-6096-H305 has multiple alarms, including one for a dynamic brake circuit failure and one for over-current protection on the L and M axes. These safeguards ensure that any linked servo motors will run smoothly and without incident.
What are the power input and current for the N-axis of the FANUC A06B-6096-H305 servo amplifier?
The FANUC A06B-6096-H305 servo amplifier has a rated power input of 3.1 kW and a rated current of 12.5A for the N-axis.
Does the FANUC A06B-6096-H305 comply with any safety standards?
Yes, it meets the safety requirements of DIN VDE 0160. This compliance guarantees its dependable functioning and meeting of critical safety and performance standards.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Type | Servo Amplifiers |
| Rated Voltage Input | 283-325 V |
| Rated KW Input | 3.1 kW |
| Max Output Voltage | 230 V |
| Rated L axis current | 3.0 A |
| Rated M axis current | 3.0 A |
| Rated N axis current | 12.5 A |
| Safety Standard | DIN VDE 0160 |
| Protection Features | Various alarms, external heatsink |
| Compliance | DIN VDE 0160 |
