Description

FANUC A06B-6111-H026#H550

To improve the accuracy and productivity of industrial machining, FANUC developed the A06B-6111-H026#H550, a high-performance spindle amplifier from the ALPHA I series. Modern production settings couldn't function without this power module, designed to maximize spindle performance in CNC machining, milling, and other precision applications.

Specifications:

The FANUC A06B-6111-H026#H550 spindle amplifier operates within a 283-339 V input voltage range for reliable power. This voltage range ensures performance, especially in harsh industrial situations. The amplifier's 29.8 W power rating shows its efficiency and ability to handle heavy loads.

This strong supply for high-precision spindle motors has a maximum voltage of 240 V and an output current of 111 A. These standards ensure high-quality and precise final products by achieving the requisite speed and torque in various machining operations.

This spindle amplifier is Power Module SPM-26i. Its 30-minute rating means the engine won't overheat or lose performance if used for long durations. The amplifier's 22 kW output power shows it can easily handle tough machining work.

Industrial amplifier performance and lifespan depend on heat dissipation. The FANUC A06B-6111-H026#H550 addresses this issue with 684 W total dissipation, including 62 W of cabinet residual heat. This amplifier's heat management mechanism keeps it cool even under strong loads, extending its lifespan.

Physical dimensions are important for integrating the A06B-6111-H026#H550 into industrial designs. Due to its 150 mm module width, it has a tiny footprint, making installation easier and space efficient. The amplifier's 10.7 kg and 13 kg shipping weight makes it portable and installable in various operational settings.

Flexibility in Use:

The ALPHA I series FANUC A06B-6111-H026#H550 suits many industrial applications. It excels at spindle-intensive milling and CNC machining.

This spindle amplifier provides consistent power and accurate control for industrial precision and efficiency. The A06B-6111-H026#H550 improves production quality and operational downtime in automotive, aerospace, and general manufacturing.

Safety Preventions:

A crucial part of designing equipment for use in industrial settings is ensuring everyone's safety. To ensure the safety of both the equipment and the personnel, the FANUC A06B-6111-H026#H550 has numerous safety measures. It has built-in overload protection to keep the amplifier and any attached motors safe from harm caused by large currents. The amplifier also has built-in thermal protection features that turn it off when it gets too hot, which keeps it from overheating and potentially catching fire.

The amplifier has been designed with strong insulation and grounding to reduce the possibility of electrical shocks further. This utmost concern for safety safeguards employees and guarantees adherence to all applicable industry norms and laws. With these precautions, the A06B-6111-H026#H550 is a safe bet for any commercial or manufacturing setting.

Frequently Asked Questions:

What are the maximum output voltage and rated output current for the FANUC A06B-6111-H026#H550?

The FANUC A06B-6111-H026#H550 has a rated output current of 111 A and a maximum output voltage of 240 V, supplying the power that high-precision spindle motors need.

How does the FANUC A06B-6111-H026#H550 manage heat dissipation, and what is its weight?

The FANUC A06B-6111-H026#H550 dissipates 684 W of total heat, with 62 W of residual heat dissipated within the cabinet. Because of its reasonable weight of 10.7 kg, it is easy to move and set up.

What are the module width and suitable motor rating for the FANUC A06B-6111-H026#H550?

Modules with a 30-minute rating are compatible with the FANUC A06B-6111-H026# H550, which has a width of 150 mm. Its small stature makes it suitable for incorporation into various industrial environments.

Product Specifications Table:

Attribute	Specification
Rated Input Voltage	283-339 V
Power Rating	29.8 W
Max Output Voltage	240 V
Rated Output Current	111 A
Type	Spindle Amplifiers
Description	Power Module SPM-26i
Heat Dissipation	Total of 684 W, with residual heat in the cabinet of 62 W
Weight	10.7 kg (shipping weight: 13 kg)
Module Width	150 mm
Rated Output Power	22 kW
