Mitsubishi MDS-B-V1-45

The Mitsubishi MDS-B-V1-45 is an axis drive of the MELDAS M500 series. This axis servo drive is available to replace any damaged equipment and comes with a guarantee tailored to the user€™s specific requirements.

Technical Details:

The Mitsubishi MDS-B-V1-45 is a high-performance variable frequency drive for precise motor control in various industrial applications. It supports a wide voltage range of 200-240V, 50/60Hz, making it suitable for global markets. The drive is capable of handling motor power up to 4.5 kW, providing robust performance for demanding applications.

Key features include advanced vector control technology, which ensures high torque performance at low speeds, and a user-friendly interface that simplifies setup and operation. The MDS-B-V1-45 supports multiple communication protocols, including Modbus, RS485, and Ethernet, enhancing its integration capabilities with existing automation systems.

Mounting Details and Precautions:

The Mitsubishi MDS-B-V1-45 is designed for versatile mounting options, allowing it to be installed in various environments. It features a compact, space-saving design with dimensions tailored for ease of installation in new and retrofit projects. Depending on the spatial constraints and operational requirements, the drive can be mounted horizontally or vertically. Its robust construction ensures durability and reliability, even in challenging industrial settings. The unit also includes standard mounting accessories, simplifying installation and reducing setup time.

It is essential to take a few safety precautions when operating the Mitsubishi MDS-B-V1-45 servo amplifier to guarantee excellent performance and safety. To prevent overheating and damage, mount the amplifier in a well-ventilated location away from harsh sunlight and corrosive gases. Additionally, keep the unit away from areas with high humidity or condensation since they may cause short circuits and other problems with operation.

Compatibility:

The MDS-B-V1-45 is engineered to be compatible with a wide range of Mitsubishi's motor products, ensuring seamless integration and optimal performance. It supports both asynchronous and synchronous motors, providing flexibility in system design. Additionally, the drive is compatible with Mitsubishi's iQ-R and iQ-F series PLCs, enhancing its interoperability within Mitsubishi's automation ecosystem. This compatibility extends to various expansion modules and accessories, allowing customized solutions tailored to specific application needs. The drive's extensive compatibility ensures it can be easily incorporated into existing systems, minimizing downtime and reducing the need for extensive reconfiguration.

Applications:

The Mitsubishi MDS-B-V1-45 is ideal for various industrial applications, including conveyors, pumps, fans, and machine tools. Its advanced control features suit applications requiring precise speed and torque control, such as textile machinery, HVAC systems, and material handling equipment. The drive's high efficiency makes it an excellent choice for food and beverage, automotive, and chemical applications. Its ability to handle variable load conditions and maintain consistent performance under varying demands ensures reliable operation and enhanced productivity across diverse industrial processes.

Frequently Asked Questions:

What are the key technical specifications of the Mitsubishi MDS-B-V1-45 servo?

It operates using a sine wave PWM control method with a transistor inverter and an Intelligent Power Module (IPM) using IGBT technology. The unit is designed for high efficiency and reliability, supporting dynamic braking and deceleration to stop.

How should the MDS-B-V1-45 be mounted for optimal performance?

The MDS-B-V1-45 should be mounted indoors, away from direct sunlight, and free from corrosive gases, combustible gases, oil mist, or dust.

With the MDS-B-V1-45, what kinds of motors can I use?

Utilizing motors like the LM-NP2L, NP4M, and other comparable models, the MDS-B-V1-45 is compatible with several Mitsubishi CNC systems. Because it supports linear and rotational servomotor systems, complicated drive system configurations, including those with multiple axes setups, can be flexibly integrated.

Product Specifications Table
