Mitsubishi HF-KP23B
SKU: HF-KP23B-NS
We have 2 in stock
Estimated delivery: September 15th - September 17th
Order for next-day shipment.
- Regular price
-
$740.00
- Sale price
- $740.00
New Surplus
$740
2 in stock
Ships today
Description
The Mitsubishi Electric HF-KP23B is a low inertia, small capacity AC servo motor in the HF-KP series, rated 0.2 kW at 3000 r/min and supplied with an integrated electromagnetic holding brake and a straight shaft. It is designed for use with Mitsubishi MR-J3 series servo amplifiers in closed-loop motion control systems.
Motors in this series are commonly found in CNC machine tools, packaging machinery, material handling systems, robotics, and general factory automation where accurate positioning and repeatable speed control are required. The B suffix denotes the electromagnetic brake option. This model has been discontinued by the manufacturer but remains widely used in installed equipment, making it a common replacement item.
Technical Specifications
| Manufacturer | Mitsubishi Electric |
| Part Number | HF-KP23B |
| Product Type | AC Servo Motor |
| Series | HF-KP |
| Rated Output | 0.2 kW |
| Rated Speed | 3000 r/min |
| Maximum Speed | 6000 r/min |
| Rated Torque | 0.64 N·m |
| Voltage Class | 200 V class |
| Power Supply | 3-phase AC |
| Inertia Class | Low inertia |
| Encoder | Absolute position encoder, 262,144 pulses/rev (18-bit) |
| Electromagnetic Brake | Yes |
| Shaft | Straight |
| Oil Seal | No |
| Flange Size | 60 mm square |
| Protection Rating | IP65 |
| Compatible Amplifier Family | Mitsubishi MR-J3 series |
-
Buying Options
-
Extend your warranty coverage at checkout 2 yrs included freePricing for this item — you’ll pick a term on the checkout page.
Extended plans are available at checkout on items $200 and up.
+1 yr → 3 total $111/yr+3 yrs → 5 total $99/yr+5 yrs → 7 total $74/yrBEST VALUE+8 yrs → 10 total $56/yrFull defect protection · free RMA evaluation & repair · same‑day replacement when in stock -
Description
The Mitsubishi Electric HF-KP23B is a low inertia, small capacity AC servo motor in the HF-KP series, rated 0.2 kW at 3000 r/min and supplied with an integrated electromagnetic holding brake and a straight shaft. It is designed for use with Mitsubishi MR-J3 series servo amplifiers in closed-loop motion control systems.
Motors in this series are commonly found in CNC machine tools, packaging machinery, material handling systems, robotics, and general factory automation where accurate positioning and repeatable speed control are required. The B suffix denotes the electromagnetic brake option. This model has been discontinued by the manufacturer but remains widely used in installed equipment, making it a common replacement item.
Technical Specifications
Manufacturer Mitsubishi Electric Part Number HF-KP23B Product Type AC Servo Motor Series HF-KP Rated Output 0.2 kW Rated Speed 3000 r/min Maximum Speed 6000 r/min Rated Torque 0.64 N·m Voltage Class 200 V class Power Supply 3-phase AC Inertia Class Low inertia Encoder Absolute position encoder, 262,144 pulses/rev (18-bit) Electromagnetic Brake Yes Shaft Straight Oil Seal No Flange Size 60 mm square Protection Rating IP65 Compatible Amplifier Family Mitsubishi MR-J3 series -
