Mitsubishi HF-SP352BK
Mitsubishi HF-SP352BK
The Mitsubishi HF-SP352BK servo motor is designed for high-performance applications requiring precision and reliability. With a power output of 3.5 kW and a rated speed of 2000 r/min, this motor is suitable for various industrial tasks.
Technical Specifications:
The Mitsubishi HF-SP352BK has a key shaft shape and no oil seal, ensuring a secure and durable connection. The motor provides a rated torque of 16.7 Nm (2360 oz. in) and a maximum torque of 50.1 Nm (7090 oz. in). The continuous rated torque for this servo is 37.2 kW/s, and the motor has an inertia moment of 75.0 J. The recommended ratio of load inertia moment to servo motor shaft inertia moment is 2, optimizing performance in dynamic applications.
The Mitsubishi HF-SP352BK servo motor has integrated electromagnetic brakes, providing immediate and reliable stopping power. These brakes ensure enhanced control and safety during operation, especially in applications requiring precise positioning and rapid deceleration.
The motor operates at a rated current of 16 A and can handle a maximum current of 48 A. Its encoder supports absolute position and incremental detection systems, with a resolution of 262144 pulses per revolution. The insulation class is 155(F), ensuring reliable operation under varying electrical conditions.
Environmental Conditions:
The HF-SP352BK is designed to operate in environments with an ambient temperature between 0 and 40 degrees Celsius (32 to 104 degrees Fahrenheit) and ambient humidity of 10 to 80%RH (non-condensing). For storage, it can withstand temperatures from 15 to 70 degrees Celsius (5 to 158 degrees Fahrenheit) and humidity levels of 10 to 90%RH (non-condensing). The motor should be installed indoors, away from direct sunlight, and free from poisonous gases and harmful materials that would otherwise get inside the servo motor and hinder its functioning.
Physical Characteristics and Applications:
The Mitsubishi HF-SP352BK has an enclosed, natural cooling structure, effectively protecting against environmental factors. It can endure vibration resistance levels of X: 24.5 m/s² and Y: 49 m/s², with a vibration rank of V10. The motor weighs 19 kg (41.9 lbs), making it manageable for various installations. The permissible radial load for the shaft is 2058 N, and the allowable thrust load is 980 N.
The HF-SP352BK servo motor is ideal for applications that require precise control and high torque, such as automation systems, robotics, and CNC machinery. Its robust design and high-performance specifications make it a dependable choice for many industries.
The Mitsubishi HF-SP352BK servo motor combines a strong design, dependable performance, and high torque. Its advanced encoder system and effective cooling design guarantee top performance in a range of industrial uses. The exacting specifications of contemporary automation and motion control systems are met by the design of this motor.
Frequently Asked Questions:
What type of encoder is used in the Mitsubishi HF-SP352BK?
The HF-SP352BK uses an encoder that supports absolute position and incremental detection systems, with a high resolution of 262144 pulses per revolution.
What does the insulation rating of the Mitsubishi HF-SP352BK indicate?
The 155(F) insulation class rating of the Mitsubishi HF-SP352BK servo motor indicates the thermal endurance of the motor's insulation system. The "F" classification specifies that the insulation can withstand a maximum temperature of 155 degrees Celsius (311 degrees Fahrenheit) without degrading.
What is the permissible load capacity for the shaft of the Mitsubishi HF-SP352BK?
The Mitsubishi HF-SP352BK servo motor can handle a radial load of up to 2058 N and a thrust load of up to 980 N. This high load capacity ensures the motor can support significant mechanical stresses, making it suitable for heavy-duty applications.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | HF-SP |
| Module Type | Servo motor |
| Power | 3.5 kW |
| Speed | 2000 rpm |
| Rated Torque | 16.7 Nm |
| Rated Current | 16 A |
| Maximum Current | 48 A |
| Vibration Rank | V10 |
| Mass | 19 kg |
| Cooling method | Natural Cooling |
