TECHNICAL SPECIFICATIONS

Range of Product Altivar Process ATV600 Product or Component Type Variable speed drive Product Specific Application Process and utilities Device short name ATV630 Variant Standard version Product destination Asynchronous motors Synchronous motors EMC filter Integrated 164.04 ft (50 m) EN/IEC 61800-3 category C2 Integrated 492.13 ft (150 m) EN/IEC 61800-3 category C3 IP degree of protection IP21IEC 61800-5-1 IP21IEC 60529 [Us] rated supply voltage 380...480 V Degree of protection UL type 1 UL 508C Type of cooling Forced convection Supply frequency 50...60 Hz - 5...5 % [Us] rated supply voltage 380...480 V - 15...10 % Motor power kW 37 kW normal duty) 30 kW heavy duty) Maximum Horse Power Rating 50 hp normal duty 40 hp heavy duty Line current 66.2 A 380 V normal duty) 57.3 A 480 V normal duty) 54.8 A 380 V heavy duty) 48.3 A 480 V heavy duty) Prospective line Isc 50 kA Apparent power 47.6 kVA 480 V normal duty) 40.2 kVA 480 V heavy duty) Continuous output current 74.5 A 4 kHz normal duty 61.5 A 4 kHz heavy duty Maximum transient current 82 A 60 s normal duty) 92.3 A 60 s heavy duty) Asynchronous motor control Variable torque standard profile Constant torque standard Optimized torque mode Synchronous motor control Permanent magnet motor profile Synchronous reluctance motor
