FANUC A06B-6102-H211#H520

The FANUC A06B-6102-H211#H520 CE Approved Alpha Spindle Module MDL SPM-11 is a high-precision automation component with signature quality and reliability. The servo motor has a rotational speed of 15000 min-1, ensuring faster and more precise machining operations.

Technical Specifications of FANUC A06B-6102-H211#H520:

The A06B-6102-H211#H520 spindle module has a maximum efficiency of 94.7%, to ensure that no energy is wasted in machining. The torque transfer capacity is up to 17.6 Nm for heavy-duty cutting operations. The low moment of inertia allows faster acceleration and deceleration during operations.

The module has an impressive IP rating of IP67, ensuring it's completely protected against dust and can withstand water immersion without damage. An F-class insulation rating can handle high temperatures of up to 155 degrees Celsius.

When it comes to power output, the A06B-6102-H211#H520 is a force to be reckoned with. The 11 kW capacity and maximum torque of 85 Nm ensure reliable and consistent performance even when faced with heavy loads. The spindle module generates a maximum power output of 22 kW to produce the highest possible torque for all machining needs.

FANUC A06B-6102-H211# H520's unparalleled performance features an advanced cooling system that regulates the temperature even in challenging environments, ensuring uninterrupted operation. With a constant torque power rate of 8.4 kW, this module is perfect for high-precision applications that require exceptional power output.

The model is designed for high-precision applications and maintains accurate performance with minimal vibration. With radial vibration of fewer than 0.02 mm/s and thrust vibration of fewer than 0.05 mm/s, this system can handle heavy loads without compromising functionality or causing excessive wear and tear.

Operating and Installation Guide:

Keeping FANUC A06B-6102-H211#H520 within specific environmental conditions optimizes its performance. The equipment will perform at its best with temperatures ranging from 0 to +45 degrees Celsius (32 to 113 degrees Fahrenheit). The humidity levels should remain between 20% to 80%, non-condensing; too much moisture can cause electrical problems or damage.

The module operates best at altitudes up to 1000 meters (3280 feet) above sea level. Keeping the equipment within the parameters is best to ensure it runs smoothly.

The electrifying FANUC alpha spindle module boasts a voltage rating of 200-240 VAC, providing the power you need to bring your ideas to life. With a maximum current consumption of 25 amps, this module will keep running smoothly without breaking a sweat.

Safety Precautions:

When installing and using FANUC A06B-6102-H211#H520, following all local and national electrical codes and regulations is important. Check the module's temperature limits to ensure it's not getting too hot under the collar. Ensure a thorough check-up on the module occasionally to ensure it's in tip-top shape.

Before unleashing the power of the FANUC alpha spindle module, give it a strong foundation by double-checking that all electrical and mechanical cords are tightly connected and well-grounded. Verify the module's compatibility with the power supply's voltage and current. It will ensure the module's firm grip on its task.

Wiring precautions:

Ensure following the wiring diagram with the FANUC spindle unit and double-check all connections before plugging it in. Secure wiring and connections will ensure that module will not get damaged from movement or heat.

Use strain relief to avoid pulling or twisting that could cause harm to both the wires and FANUC A06B-6102-H211#H520. Protect wiring using the appropriate conduit or tubing to ensure safety from moisture, dust, or other debris that could damage it.
