TECHNICAL SPECIFICATIONS

FANUC A06B-6114-H303

 FANUC's A06B-6114-H303 servo amplifier module merges digital precision and power, achieving unprecedented control speeds for CNC machines or any other industrial application. Boasting advanced engineering from the experts at FANUC Corporation, this SVM3-20/20/20i device sets a new benchmark in motion performance and accuracy.

Technical Specifications

The A06B-6114-H303 servo amplifier module is a high-performance device for precise and dependable motion control in industrial automation applications.

The module has a 200-240VAC power input voltage and a rated current of 6.5A, with a nominal current peak of 20A. The module has a small footprint, measuring 195mm x 300mm x 220mm and weighing about 2.6kg.

The total heat dissipation of the servo amplifier is 21W. The Servo amplifier can control both AC and DC servo motors with power outputs of up to 30 kW.

Operating Conditions

The module, which has the model number A06B-6114-H303, was developed to withstand the most severe environmental conditions, including heat waves of up to 55 degrees Celsius, extremely high humidity, and extreme vibration and shock.

A stable AC power supply with a voltage range of 200-240VAC at 50/60 Hz is required for the amplifier. Ensure the power supply meets these specifications to avoid electrical problems or amplifier damage. Ensure there is enough space around the amplifier to allow for proper airflow and to avoid blocking the cooling fans or vents, as it requires adequate cooling to avoid overheating.

This device can resist vibrations ranging from 10-200 Hz with a 0.5G force at 11 ms intervals, making it highly resilient in industrial settings where heavy-duty strain is common. Additionally, it offers 20G impact protection against shocks so that it can withstand shocks with a force of 20G!

Installation and Transportation

To ensure safe and reliable operation, the servo amplifier module must be installed and transported correctly. Handle the module carefully during transportation to prevent any damage to the module or its components.

The A06B-6114-H303 module should be installed appropriately, away from heat, moisture, and vibration. The manual's guidelines should also establish proper grounding and electrical connections.

To prevent dust, dirt, and other contaminants from entering the amplifier, place it in a dry, clean, and well-ventilated environment. Avoid exposing the amplifier to high temperatures or humidity, as these can impact its performance and lifespan. Ensure that all connections are securely in place and properly configure the module for the specific application before turning it on.

The module should be transported in its original packaging to avoid physical damage during transit. The ambient temperature should be kept between -20°C and 60°C during transportation to avoid damage to the module.

Safety Precautions

It is necessary to power down the system before making any connections or alterations to the A06B-6114-H303 module. When handling the module or any associated equipment, use the appropriate personal protective equipment like gloves and safety glasses.

Ensure you accurately ground the system's electrical supply and make all electrical connections. The module has several built-in safety features, such as protection against overheating, overvoltage, and overcurrent, which work together to prevent the connection or the module from becoming damaged.

Ensure all connections are secure and properly configure the module for use with the application before turning it on.
