TECHNICAL SPECIFICATIONS

FANUC A06B-6093-H152

This module A06B-6093-H152 is a servo amplifier unit produced by FANUC Corporation, part of the FANUC Alpha Series of servo amplifiers. Compared to the A06B-6093-H111 model, the A06B-6093-H152 has a higher output rating, with a maximum output of 400V and 30A. It makes it suitable for use in applications that require higher power output, such as large CNC machines or industrial robots.

Technical Specifications of A06B-6093-H152:

The module A06B-6093-H152 offers position control, speed control, and torque control, giving users a range of options for controlling servo motor movements based on their specific needs in terms of control modes. Additionally, the module includes built-in protection functions, such as overcurrent, overvoltage, Undervoltage overheat, overspeed, and overload protection, which help to ensure reliable and safe operation in industrial environments.

The module A06B-6093-H152 is designed to operate within a temperature range of 0-55°C (32-131°F) and a relative humidity range of 10-95% (non-condensing), making it suitable for use in a variety of industrial settings. Its dimensions of 200x400x300mm and weight of 15kg (33 lbs) make it a compact and portable component easily integrated into different systems.

Operating and Installation Instructions:

The operating and installation instructions for the A06B-6093-H152 servo amplifier module provide a comprehensive guide on installing, operating, and maintaining the module to ensure reliable and safe operation in industrial settings.

The instructions in module A06B-6093-H152 typically begin with a section on safety precautions; the module installers, operators, and maintainers should take measures to prevent accidents and injury. This section highlights the importance of grounding the module, disconnecting the power supply before performing maintenance, and avoiding contact with live components.

Wiring Safety Measures:

The Wiring safety of module A06B-6093-H152 measures are essential to ensure the safe and reliable operation of the servo amplifier module in industrial settings. Preventing electrical shock, equipment damage, and other hazards is important by ensuring proper wiring.

One critical wiring safety of the A06B-6093-H152 module measure is to ensure proper module grounding. It ensures the ground connection is secure and the grounding conductor appropriately sized for the current load. Failure to properly ground the module can result in electrical shock or damage to the module or other equipment.

Ensure correct module wiring using the diagrams provided in the installation instructions, reducing the risk of equipment damage. It is crucial to follow standard electrical safety procedures of the A06B-6093-H152 module, such as disconnecting the power supply before performing any maintenance or repairs, wearing appropriate personal protective equipment, and avoiding contact with live components.

By following these wiring safety measures and adhering to standard electrical safety procedures, users can ensure the safe and reliable operation of the A06B-6093-H152 servo amplifier.

General Precautions:

Using appropriate personal protective equipment is one of the general precautions. When working with the module, gloves, safety glasses, and protective clothing are important to protect against injury from sharp edges or flying debris.

Ensuring proper ventilation is also essential for the safe operation of the A06B-6093-H152 module. The module generates heat during operation, and adequate ventilation is required to dissipate this heat and prevent overheating. You can achieve this by installing the module in a location with good airflow or external cooling devices.
