Mitsubishi MDS-B-SP-260

The Mitsubishi MDS-B-SP-260 is a High-performance spindle drive made to be precise and dependable for use in various industrial settings. It has sophisticated control mechanisms to guarantee life and peak performance.

Technical Details:

The MDS-B-SP-260 spindle drive unit operates with an output voltage of 200-230V and a continuous output current of 0.2A. The unit utilizes a sine wave PWM control method and incorporates a transistor inverter system using an intelligent power module (IPM) with IGBT technology. This design ensures efficient and stable operation under various load conditions.

The MDS-B-SP-260 spindle drive supports dynamic braking and deceleration to stop, providing reliability and smooth operation. The tolerable ambient temperature for the unit ranges from 0°C to 55°C, with a storage temperature range of -15°C to 70°C. The unit operates effectively in environments with up to 90% relative humidity, with no dew condensation.

The MDS-B-SP-260 has connectors and terminal blocks for seamless integration with other system components. Key connectors include CN1A and CN1B for CNC and battery unit connections, CN2 for motor end detector connections, and CN3 for machine end detector connections. The unit also features a TE1 terminal block for motor drive outputs and a TE2 terminal block for converter voltage inputs.

Installation Guide:

Ensure adequate ventilation and no exposure to various harmful gases and foreign particles before installing the MDS-B-SP-260 spindle drive unit.

Install the unit on a non-combustible surface with the help of proper tools so that the drive is firmly placed. Additionally, ensure that the installation site allows proper airflow.

Connect the unit to the power supply, motor, and other system components using the provided connectors. Make sure that all connections are secure and correctly aligned to prevent electrical faults. Set the servo and spindle parameters according to the specifications provided on the NC screen. Adjust settings such as speed gain and zero-point return to optimize performance based on the specific application requirements.

Precautions:

To prevent overheating of MDS-B-SP-260, situate it in an area with enough ventilation. Maintain effective heat dissipation by routinely checking and cleaning cooling fans and heat sinks. Please ensure all electrical connections are safe and undamaged by thoroughly inspecting them twice. The device may malfunction or sustain damage as due to improper wiring or loose connections.

Steer clear of the unit exposed to strong sunshine, extreme heat, or excessive humidity. Keep the device somewhere cold and dry to avoid component deterioration when not in use.

Verify that an external dynamic brake unit is correctly attached and set up if the device lacks built-in dynamic brakes. By doing these preventive measures, the safety of MDS-B-SP-260 during emergency stops and deceleration stages will be improved.

Frequently Asked Questions:

How can the dynamic brake function be utilized with the MDS-B-SP-260?

If the MDS-B-SP-260 does not have built-in dynamic brakes, an external dynamic brake unit should be connected and configured according to the specified wiring diagram. Make sure the dynamic brake unit is integrated with magnetic brakes for proper functioning.

What are the cooling requirements for the MDS-B-SP-260?

For proper airflow of the MDS-B-SP-260, install a fan that operates at a velocity of at least 2m/s to dissipate heat generated by the unit effectively.

What is the input voltage type for the MDS-B-SP-260?

The MDS-B-SP-260 inputs a DC voltage of 200-230V and gives an AC output.

Product Specifications Table

Attribute Specifications
Series MDS-B series
Module Type MDS Spindle Drive
Max output capacity 26kW
Continuous rated output 190 W
Frequency Range 50-60 Hz
Voltage Range 200 to 230V
Phase 3
Rated output current 97 A
Manufacturer Mitsubishi
Product Status Active

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
IAC Certified Refurbished MDS-B-SP-260-R 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.
