Mitsubishi MDS-B-V2-3510

The Mitsubishi MDS-B-V2-3510 is a high-performance servo drive unit designed to meet the demands of modern industrial applications. This unit is part of Mitsubishi's MDS-B series, known for its strong design and advanced capabilities in motion control systems. Its compact and efficient design makes it suitable for various applications requiring precise and reliable motion control.

Technical Description:

The MDS-B-V2-3510 operates with a continuous output of 3.5 kW and can handle peak outputs significantly higher, making it ideal for applications demanding high torque and rapid acceleration. It supports input voltages of 200-230 VAC, ensuring compatibility with standard industrial power supplies. The unit incorporates advanced digital signal processing (DSP) technology to deliver high-speed and accurate servo motor control. This results in improved performance in terms of speed, positioning accuracy, and overall system efficiency.

Mounting Details:

Mounting the MDS-B-V2-3510 requires careful consideration to ensure optimal performance and safety. The unit should be installed in a well-ventilated area to prevent overheating. It features a modular design that allows for easy integration into control panels. The unit should be mounted vertically with sufficient clearance for proper air circulation. It is essential to follow the manufacturer's guidelines regarding the torque specifications for mounting screws to ensure secure installation.

Precautions:

Several safety precautions must be observed when installing and operating the MDS-B-V2-3510. First and foremost, ensure that the power is turned off before performing any installation or maintenance work to prevent electric shock. The unit should be grounded properly to avoid electrical hazards. Avoid exposing the unit to direct sunlight, high humidity, or corrosive environments, as these conditions can damage the electronic components. Additionally, users should not attempt to disassemble or modify the unit, as this can void the warranty and lead to equipment failure or safety hazards.

Applications and Compatibility:

The MDS-B-V2-3510 suits various applications, particularly robotics, CNC machinery, and automated production lines. Its high precision and reliability make it ideal for tasks requiring accurate positioning and speed control, such as milling machines, lathes, and assembly robots. The unit's ability to handle high torque and rapid acceleration makes it suitable for heavy-duty applications, including material handling and packaging machinery.

This servo drive unit is compatible with a variety of servo motors, allowing for flexible system design and integration. It works seamlessly with Mitsubishi's range of servo motors, ensuring optimal performance and compatibility. Additionally, the MDS-B-V2-3510 can be integrated with various control systems, including PLCs and CNC controllers, making it a versatile choice for different industrial automation setups. The unit supports multiple feedback devices, such as encoders and resolvers, providing flexibility in system configuration and ensuring precise control over the motor's performance.

Frequently Asked Questions:

Is it possible to combine the MDS-B-V2-3510 with different control systems?

The MDS-B-V2-3510 can be integrated with PLCs, CNC controllers, and other control systems. Encoders and resolvers are just some feedback devices it supports, giving system setup freedom and guaranteeing accurate motor control.

What are the mounting requirements for the MDS-B-V2-3510?

The MDS-B-V2-3510 should be mounted vertically in a well-ventilated area with sufficient clearance for air circulation.

Can the user modify the MDS-B-V2-3510 if needed?

No, it is severely dangerous for users to disassemble or modify the servo by themselves. The MDS-B-V2-3510 servo is a compact and closed unit, not suitable to be repaired by nonprofessionals.

Product Specifications Table

Attribute	Specifications
Series	MDS-B series
Module Type	Servo Drive
Output Current	16 A / 6.8A
Power	3.5 kW / 1.0 KW
Frequency Range	50-60 Hz
Voltage Range	200 to 230V
Phase	3
Rated Capacity	22 kW
Net Weight	NA
Braking	Dynamic brakes
