TECHNICAL SPECIFICATIONS

MR-J2S-200CP

The JS2 family of efficient servo amplifiers from Mitsubishi is led by this integrated positional servo amplifier MR-J2S-200CP, which requires professional installation and operation within specific environmental conditions for optimal performance.

The versatile model MR-J2S-200CP combines three basic points of data tables but can be adapted with servo configuration software to feature up to thirty-one data points. To provide comprehensive control and flexibility, the amplifier offers a variety of operational modes, including automatic operation, manual operation, and manual home position returns.

Technical Specifications of MR-J2S-200CP:

With the MR Configurator software, this high-performance AC servo amplifier model MR-J2S-200CP is a versatile machine that stands out with its lightweight of 2 kg and integrated dynamic braking system for powerful inertia moments up to 30.

The model MR-J2S-200CP operates with a variable three-phase supply voltage between 200 and 230 VAC, optimally powered within the recommended frequency range of 50 to 60 hertz.

This model MR-J2S-200CP boasts high-end features such as absolute position detection, backlash function, software stroke limit, and an external analog signal override. It is also designed with a resilient servo amplifier able to withstand vibrations up to 5.9 m/s2 without compromising performance.

Ambient Conditions for Operation and Installation:

This model MR-J2S-200CP is designed to perform at its best between 0 - 55°C in conditions with a maximum relative humidity of 90%. The model should be installed and operated at locations protected from direct sunlight. Malicious environmental conditions, such as dust or oil mist, must not compromise the optimal functioning of this product.

For optimum performance, even in extreme elevations up to 1,000 m above sea level, the servo amplifier MR-J2S-200CP requires installation within a control cabinet with an enhanced protection rating.

To ensure optimal operating conditions within the control cabinet, it is advised to leave at least 100 mm of space between each servo amplifier and the top interior surface. This separation will prevent overheating from exceeding ambient temperature levels.

Software Features and Requirements:

Maximize your user experience with the software by running it on a Pentium® 133MHz, 150MHz, or 300 Mhz processor. Ensure that you have at least 60 MB of disk space available and are operating Windows XP (or any later version).

With MR Configurator software (version MR2JW3-SETUP151E or higher), powerful tools such as machine simulation, an analyzer, and a gain search can be accessed via the servo amplifier's integrated communication feature.

This software has the capability to alter, track and monitor multiple parameters including List-display, Detailed display, and Device settings. Users can optimize their performance for optimal results by taking advantage of these features.

Protection Specifications and Safety Precautions:

To ensure safety, the MR-J2S-200CP servo amplifier's cover should only be removed when necessary for wiring or inspection. Take caution - a retained current may cause an electric shock upon contact.

The MR-J2S-200CP model's advanced protection features guard against common operational hazards, such as overcurrent and regeneration overvoltage. At the same time, an electronic thermal relay safeguards the servo amplifier from overload. This system also defends against potential catastrophes like under and over-speed, encoder error, and instantaneous power failure.

Exercise caution when handling the servo amplifier, as exposed high-voltage connections may cause electric shock if its front panel has been removed. Charge responsibly and avoid potential danger.
