TECHNICAL SPECIFICATIONS

MR-J2S-60A-S004

The 1.1-kilogram Mitsubishi servo drive MR-J2S-60A-S004 is an incredibly versatile, highly effective model designed for various applications and with both dynamic braking and current control systems built in.

The model MR-J2S-60A-S004 robust three-phase power supply allows for wide flexibility in operating voltage, from 170 VAC up to 253 VAC. Furthermore, the device offers a variety of control modes with which they can effortlessly transition between position control, speed regulation, and torque manipulation as needed.

Technical Specifications of MR-J2S-60A-S004:

The servo amplifier MR-J2S-60A-S004 is capable of precise motion control, providing three distinct modes; position, speed, and torque. Advanced thermal management ensures safe operation with a natural convection system to dissipate heat buildup within the device's housing.

This model MR-J2S-60A-S004 features various safeguards to ensure the integrity of the operations - from an overcurrent cutoff and regenerative overvoltage cutoff to encoder error protection, sudden power outage security measures, and excessive speed countermeasures.

The model MR-J2S-60A-S004 exhibits remarkable tolerance for voltage fluctuations for single-phase voltage supply, from 207 to 253 VAC. A precise position is obtained via a rapid pulse train which controls the motor's rotational speed and direction with incredible accuracy.

The open collector can handle pulse frequencies of up to 200 kpps, and the differential receiver boosts that rate to 500 kpps. Both speed controls offer ratios ranging from 1:2000 - 1:5000 for an impressive range of control options.

An analog speed command of 0 - 10 VDC, alongside an analogous torque input range from 0 to 8 VDC, allows users to precisely control motor functions. Utilizing a parameter setting or external analog signal can expand this optimization potential by extending the speed limit to 10 VDC in torque control mode.

Operating and Installation Conditions:

The model should be positioned vertically and kept far from vibration sources for optimal performance. When installing a servo amplifier correctly, it's necessary to maintain 40 mm of clearance above, along with 10 mm on each side, for improved stability.

This model MR-J2S-60A-S004 operates best within a temperature range of 0 to 55 degrees Celsius and must be stored in environments between -20 and 65 degrees Celsius. Additionally, the relative humidity should not exceed 90% while an experienced technician conducts the setup.

Ensure that the control cabinet is of an appropriate protective class for servo amplifier installation, and leave plenty of room between it and the ceiling to ensure proper ventilation. It will prevent temperatures from exceeding those in their surroundings.

Standard Cautions

This versatile model MR-J2S-60A-S004 was crafted for diverse applications, ensuring that it can be safely incorporated into any situation without endangering human life.

Utilizing modified or incomplete servo amplifiers is strongly discouraged. Careful consideration should ensure that precisely configured model parameters are not tampered with.

Extensive testing during production ensures that each servo amplifier is held to a high standard of excellence. To protect against potentially disastrous scenarios, deploying this product in vulnerable locations must consider a robust backup or failsafe system to minimize losses should the device fail.

To improve signal integrity, sophisticated noise filtering techniques are essential for a servo amplifier near other electronic devices. It can help limit the disturbance caused by electromagnetic interference.
